Cushion Rebounce Silicon Polyurethane Material SPU Synthetic Basketball Court Flooring
Product Description
Jiangsu ChangNuo New Materials Co.,Ltd was founded in 2009.We are the one stop material supplier in China for high quality sport matrial,such as SPU court , running track , artificial grass, rubber particle and we're also engaging in the construction of sports venues.It is a high-tech enterprise integrating R&D, production and sales of new materials for sports venues.
What is SPU?
SPU sports flooring is made by silicon PU / silicon polyurethane materials. It has been implemented for the past 10 years and created a classic name for sports flooring. It is widely used for sports flooring and playground field, especially for outdoor fields.
It’s a design based on human kinetics and physical characteristics flooring system, with hard top layer
combined with soft rebound cushion lower layer structure. It’s suitable to lay on concrete or asphalt
substrates. The cushion layer is formed by single component modified polyurethane and top up with two
component modified acrylic resilience layer.
The excellent performance of SPU:HARD TOP SOFT DOWN
The purpose of building sports courts is to ensure a professional,safe,healthy sports condition-the characteristicsof hardness will bring the professional sporting feeling;the cushion effectively increasing the shock absorption and reduce the incidence of injuries to ankles, joints and ligaments. At the same time,it should reduce abrasion caused by falling and accident
Charatereristics:
a, The purpose of building sports courts is to ensure a professional,safe,healthy sports condition.
b, the characteristics of hardness and rebounce will bring the professional sporting feeling.
c, the cushion effectively increasing the shock absorption and reduce the incidence of injuries to ankles, joints and ligaments.
d, At the same time,it should reduce abrasion caused by falling and accident.
Detailed specification of product
Standard of Sports Performance
| Item | test project | technical requirements | test results |
| 1 | Shock absorption rate (%) | Fr≥12 | 21 |
| 2 | The springback value(%) | ≥20 | 30 |
| 3 | Sliding friction coefficient | 0.4≤u≤0.7 | 0.53 |
| 4 | Compression recovery rate(%) | ≥95 | 97 |
| 5 | Hardness(Shore A),20℃ | 60-80 | 68 |
Environmental Performance Standard
Based on considerations of social environmental security responsibility
Perform interior decoration decorate material national mandatory standard, do real non-toxic harmless green material.
Standard Testing Result of SPU
| Item | test project | technical requirements | test results |
| 1 | Volatile organic compounds(VOC)(g/L) | ≤670 | 91 |
| 2 | benzene(%) | ≤0.3 | Did not check out |
| 3 | Toluene ＋xylene＋ ethyl benzene(%) | ≤30 | 5 |
| 4 | The free diisocyanate(TDI＋HDI)(%) | ≤0.4 | Did not check out |
| 5 | Halogenated hydrocarbon(%) | ≤0.1 | Did not check out |
| 6 | Soluble heavy metals(mg/kg) | plumbum Pb | ≤90 | Did not check out |
| Cadmium Cd | ≤75 | Did not check out |
| chromium Cr | ≤60 | Did not check out |
| mercury Hg | ≤60 | Did not check out |
Durable Performance Standard
Based on the owner or operator, construction and maintenance
Reflect the quality level of the site, and durable time limit
Technical data for SPU Sports Flooring
| Item | test project | technical requirements | test results |
| 1 | Tensile elogation,% | ≥400 | 1112 |
| 2 | The tensile strength,Mpa | ≥1.8 | 3.5 |
| 3 | Artificial climate ageing resistance(300h) No bubbles, no peeling, no crack； | pulverization≤grade 1,△E≤6.0 | No bubbles, no peeling, no crack； pulverization＝grade 0,△E＝0.57 |
| 4 | Wear resistance(750g/500r),g | ≤0.050 | 0.031 |
| 5 | Durability, aging experiment(168h) | Tensile elongation,% | ≥300 | 853 |
| The tensile strength,Mpa | ≥1.3 | 1.6 |
| 6 | Resistance to water(168h) | No bubbles, no peeling, allowing a slight color change,recovery after 2h | No bubbles, no peeling, no discoloration |
| 7 | Flame retardant level | I | I |
Excellent performance
1· More professional
Professional flexibility, excellent security protection.
High ductility, excellent wear resistance, decorative floor function
2· More environmental protection
High standards of environmental protection, indoor and outdoor can be laid
3· More beautiful
The original creation of sand color structure , break the bottleneck of “ red green and blue
4· Visual.More effective
Mixed function, active site "one place too many uses" is the "golden choice" for building;
Our advantages (Why choose us?)
1. 1. Our products are odorless and non-toxic.
2. We have two main production bases and can make every kinds of SPU venues, running track, artificial grass, sports flooring construction and colloidal particles.
3. 3. We have more than 20 years' development and production history.
4. 4. Exceed ten million squre meters every year in the world.
Product Structure:
Project Case
